Evolite Hazebox 2000 XL – Professional Stage Haze Machine
Overview
The Evolite Hazebox 2000 XL is a professional stage haze machine designed to deliver consistent, even haze diffusion in clubs, theatres, live stages, and large event venues. Housed in a durable integrated flight case, it is ready for transport and deployment without the need for additional protection, making it ideal for touring, rental, and mobile production use.
Featuring a powerful 2000 W heating element, a fast 3-minute warm-up time, and a high haze output of up to 2000 m³/min, the Hazebox 2000 XL enhances lighting beams and atmospheric effects with a fine, stable haze—without oversaturating the room. Its large 5 L fluid tank and ultra-efficient 0.18 L/h fluid consumption make it a dependable solution for long events with minimal refills.
Design and Build Quality
Built for professional environments, the Hazebox 2000 XL is mounted within a robust flight case for safe transport and easy handling. An integrated anti-leak plug system helps prevent fluid spills during transit, making it particularly well suited to mobile setups, touring productions, and rental inventories.
Operation is simple and intuitive thanks to the backlit LCD display and rotary navigation wheel, allowing quick access to settings and DMX addressing. The machine is designed for use with water-based hazer fluids only, ensuring clean, consistent output and reliable performance in professional lighting applications.
Key Technologies and Features
- Professional Haze Output: Produces a fine, even haze to enhance beams and atmospheric lighting.
- High Output Performance: Maximum haze output of up to 2000 m³/min for large venues.
- 2000 W Heating Element: Powerful heater for stable and consistent haze generation.
- Fast Warm-Up: Ready to operate in approximately 3 minutes.
- Continuous Haze Production: Designed for uninterrupted operation during long sessions.
- 2-Channel DMX Control: Independent control of haze output and fan speed.
- Backlit LCD & Navigation Wheel: Easy setup, menu navigation, and DMX addressing.
- Large 5 L Fluid Tank: Reduces refill frequency for events and installations.
- Ultra-Efficient Consumption: Low fluid usage of just 0.18 L/h.
- Integrated Flight Case: Ideal for transport, touring, rental stock, and mobile rigs.
- Anti-Leak System: Helps prevent fluid leakage during transport.
- Water-Based Fluids Only: Compatible with professional water-based hazer liquids.
Specifications
| Specification | Details |
|---|---|
| Product Type | Stage haze machine (flight case integrated) |
| Heater Power | 2000 W |
| Warm-Up Time | Approx. 3 minutes |
| Maximum Output | Up to 2000 m³/min |
| Fluid Tank Capacity | 5 L |
| Fluid Consumption | 0.18 L/h |
| Fluid Type | Water-based hazer fluid only |
| DMX Control | Yes – 2 channels (output and fan speed) |
| Display | Backlit LCD with navigation wheel |
| Anti-Leak System | Anti-leak plug system |
| Fuse | 5 A / 250 V |
| Voltage | 230 VAC / 50 Hz |
| Flight Case Dimensions | 490 × 300 × 480 mm |
| Weight | 23 kg |
| Approvals | CE / RoHS / EN 2014/30/EU, EN 2011/65/EU, EN 2014/35/EU |
| Warranty | 3-year warranty |
Performance and User Experience
The Evolite Hazebox 2000 XL delivers a smooth, professional haze that enhances lighting effects without overwhelming the venue. Its high output makes it suitable for large spaces, while the low fluid consumption and large tank minimise running costs and maintenance. With precise 2-channel DMX control over output and fan speed, it integrates seamlessly into professional lighting systems, giving operators accurate control over atmosphere throughout a performance.
Q&A Section
Q: What is the Hazebox 2000 XL best used for?
A: It is ideal for producing a fine, even haze that enhances beams and lighting effects in clubs, theatres, and stage productions.
Q: Can it be controlled via DMX?
A: Yes. It supports 2 DMX channels for independent control of haze output and fan speed.
Q: What type of fluid should be used?
A: The machine is designed for water-based hazer fluids only.
Q: How long is the warm-up time?
A: Approximately 3 minutes.
Q: Is it suitable for mobile and touring use?
A: Yes. The integrated flight case and anti-leak system make it ideal for transport and frequent setups.
